Lightnovo Products
Raman spectrometers and Raman microscopes
Lightnovo is proud to present
miniRaman spectrometers – world smallest Raman spectrometers
- Raman shift and Raman intensity calibration during each acquisition;
- two laser sources: 660nm and 785nm;
- internal battery for in-field operation;
- wire and wireless data transfer;
- operation from PC and Android.
miniRaman microscopes – world smallest confocal Raman microscopes
- up to 3 laser sources (660nm and 785nm);
- motorised 3D stage (travel range 26x26x26mm, closed loop, resolution 100nm);
- internal battery for in-field operation;
- data transfer: usb 3.0;
- operation from PC.
RG Raman spectrometer
RG Raman spectrometer perfectly suits for any kind of demanding Raman spectroscopy applications that require high spectral resolution, extremely stable laser power, high sensitivity and broad spectral range (from low frequency to high frequency Raman shift).
Technology is based on high throughput transmittance diffraction optics with up to 85% efficiency from sample to detector.
There are four different models of RG Raman spectrometer depend on laser wavelength (405 nm, 532 nm, 633 nm and 785 nm).
RG Raman microscope
RG Raman microscope perfectly suits for any kind of demanding Raman spectroscopy applications that require high spectral and spatial resolution, long mapping range, extremely stable laser power, high sensitivity and broad spectral range (from low frequency to high frequency Raman shift).
RG Raman microscope provides diffraction limited spatial resolution, extremely high throughput and additionally equipped with transmitted visible light microscopy on separate camera sensor. RG Raman microscope can be used in upright microscopy and inverted microscopy configurations. All what is need for switching between modes – flip the device from top to bottom.
THOR – advanced Raman microscopes
- mirrorless Raman beam delivery;
- up to 4 lasers(457nm, 532nm, 633nm, 785nm or custom);
- diffraction limited resolution;
- super fast polarized Raman microscopy;
- low frequency Raman microscopy;
- fast optical shutter technology (<1ms).
